Two Heads Cap/Tubular Embroidery Machine

Suitable for high-end customization of embroidery processes for garments, bags, shoes, hats, toys, and other products.

Video Download

Please wait a moment. The video is loading...

Equipment Advantages

New computer control system with a friendly HMI, flexible operation, large storage capacity, and high-precision machine operation.
Power Failure Protection Function: In the event of a sudden power outage, the machine can automatically locate the pause state before the power failure and resume embroidery.
Pattern rotation and proportional scaling: Patterns can be scaled up or down in 1% increments, ranging from 50% to 200%, and rotated in 1° increments, with a rotation range from 0° to 89°.
Functions include rotating, scaling, copying, deleting, and editing patterns. The system allows for software limit setting, making it convenient for specialized embroidery tasks such as tubular embroidery and cap embroidery.
The frame forward/backward key allows frame movement based on stitches, color changes, or a specified number of stitches.
New type of table board with high hardness and excellent wear resistance.
Standard Configuration: Casters are equipped in the machine, making transportation and movement more convenient.
Standard Configuration: Thread guide tube ensures stable thread movement and prevents thread tangling or detachment.
Optional Safety Light Curtain.
Equipped with automatic color changing, dynamic thread trimming by motor, servo motor thread hooking, and automatic thread broken detection.

Model	Working Area (mm)	Net Weight (kg)	Machine Installation Size (L×W×H)
GOACE-FE-122	600mmx400mm	365kg	1450mmx1130mmx930mm
GOACE-FE-122	600mm×500mm	370kg	1450mmx1130mmx930mm
GOACE-FE-124	600mmx400mm	580kg	2000mmx1130mmx930mm
