Rotary Head Precision Sewing Machine – Baffle Box Duvet
Suitable for the sewing of Baffle Box Duvets, Sewn-Through Duvets, Baffle Sleeping Bags, and Sewn-Through Sleeping Bags, among other home textile products.
.png)
Please wait a moment. The video is loading...
Equipment Advantages
- Sewing head and rotary hook assembly can achieve precise, synchronous rotation at any spatial angle, ensuring the sewing process maintains a forward stitch.
- X and Y drive axes use high-precision ball screw and linear guide structures to ensure stability and accuracy during high-speed, high-strength operation.
- Baffle tape feeding mechanism uses stepper motor drive to achieve perfect synchronization between tape feed and needle movement, with adjustable feed speed and automatic cutting to preset length.
- Fully servo system ensures highly accurate sewing.
- High-speed liftable sewing head with a maximum lifting height of 100mm to accommodate products of varying thicknesses.
- RaiseAgain proprietary integrated control software for fully integrated mechanic and electronic operation.
- Needle bar and rotary hook shaft feature DLC (diamond-like carbon) coating for wear resistance, supporting oil-free or low-oil operation at high speed.
- Core moving parts employ SMC atomizing oil injection with freely adjustable spraying frequency.
- Supports upper and lower thread detection, stitch counting, and automatic thread trimming.
| Model | Working Area (mm) | Power (kw) |
|---|---|---|
| GOA-QC-LM-PQ-1-2600×2800-B-ZS-VR2-LH100,RH,UTC,AFC-3P380V | 2600mm×2800mm | 7.5KW |
